The AP433RX2 universal remote control system is an ideal upgrade for older garage door operators for which replacement handsets are no longer available.
AP433TX4 four channel keyfob
dimensions - 53mm x 33mm x 13.5mm
Up to four doors or gates can be
controlled from each AP433TX4 keyfob
(The AP433RX2 is a two channel receiver unit and
may be connected to two separate door or gate motors)
Quick & simple DIY installation
Can be fitted within about 5 minutes with no technical knowledge, we
even supply a screwdriver !
Suits most garage door operators including Alltronik, Apex Millennium, Bosch, Chamberlain, Liftmaster, Rallye
& any other system with connections
for a wall mounted pushbutton control.
The receiver unit simply plugs into a domestic mains socket and is supplied with 7Mtrs of low voltage two core flex for connection to the wall mounted pushbutton switch terminals on a garage door operator system
(you may connect the wires from the new receiver to the terminals on your wall switch or directly to the wall switch terminals inside the electric operator casing, whichever you prefer!)
Note: It's essential that your door functions normally from the pushbutton so please confirm this before ordering a remote control upgrade kit.
(if a pushbutton switch has not been installed you can test your system by locating the pushbutton terminals on your door operator unit and briefly shorting them together with a metal object)
